Paint Spraying Drone
Industrial
Product Overview
The GA-IN-PS Paint Spraying Drone from Garuda Aerospace is an advanced aerial coating platform designed for efficient painting and surface treatment of large industrial structures and difficult-to-access assets. Equipped with a precision paint spraying mechanism, pressure-regulated spray gun, and real-time monitoring camera, the drone ensures uniform coating quality while minimizing human risk. The system significantly reduces the need for scaffolding and manual labour in hazardous environments.
Technical Data
Model Name
GA-IN-PS
Max Payload
10 kg
All Up Weight
25 kg
Max Speed
5 m/s
Max Endurance
25 mins
Max Height
100 m
Spraying Distance
2 m
Dimensions
2032 x 2032 x 580 mm
Ceiling Height
120 m
Speed of Climb
3 m/s
System Features
Precision aerial paint spraying system.
Uniform coating across large vertical surfaces.
Pressure-regulated spray gun for controlled paint flow.
Real-time camera monitoring for accurate spraying.
Reduced scaffolding and rope-access requirements.
Faster coating of large industrial assets.
Improved worker safety in hazardous environments.
Efficient deployment for industrial maintenance operations.
Payload & Sensor System
RGB Camera
Real-time visual monitoring during spraying operations for better accuracy and operator control.
Paint Spraying Mechanism
Controlled paint distribution system designed for industrial coatings and aerial surface treatment.
Applications
Industrial Infrastructure
Construction & Maintenance
Energy & Utilities
Garuda's Advantage
Eliminates need for scaffolding in many scenarios.
Reduces worker exposure to hazardous heights.
Consistent paint quality and coverage.
